AVIC Hangte No. 10 Synthetic High-Temperature Hydraulic Oil 170 kg/200 L
Packaging specifications：170 kg/200 L
Order Hotline：+86 18624936708
Excellent cleanliness and anti-foaming properties. Operating temperature range: -61°C to 160°C.
No. 10 Synthetic High-Temperature Hydraulic Oil
Overview:
AVIC Hangte No. 10 Synthetic High-Temperature Hydraulic Oil is refined using synthetic base oils and multifunctional additives. It is suitable for use in aviation hydraulic systems operating under high-temperature, high-pressure conditions, as well as high-performance hydraulic transmissions subject to large temperature fluctuations.
Performance Features:
◎Excellent high-temperature stability and oxidation stability
◎Excellent high- and low-temperature performance and shear stability
◎Excellent rust and corrosion resistance
◎Excellent cleanliness and anti-foaming properties
◎Excellent compatibility with sealing materials
Scope of Application:
Suitable for use in high-precision hydraulic systems in aircraft hydraulic equipment, special vehicles, and other equipment with special requirements for extreme temperatures.
Implementation Standard:
Q/ZHHT 005-2024
Typical Data:
Item | Quality Indicator | Test Results |
Appearance | Red transparent liquid | Red transparent liquid |
Density, kg/m³ | ≤850 | 818.9 |
Pouring Point, °C | ≤ -60 | -61 |
Flash Point (Open), °C | ≥120 | 160 |
Fire Point, °C | ≥160 | 175 |
Kinematic Viscosity, mm/s 50°C -50°C | ≥10 ≤1600 | 10.83 1580 |
Corrosion (70°C ±2°C, 24h), Level | Level ≤2 | 1b |
Precautions:
◎ Follow relevant safety procedures when handling.
◎ Store away from high temperatures, sources of ignition, and flammable materials.
◎ Store in a well-ventilated area.
Specifications:
3.5kg/drum, 15kg/drum, 170kg/drum.
